AXK5S00337YG
| Manufacturer Part | AXK5S00337YG |
|---|---|
| Manufacturer | Panasonic Electric Works |
| Description | CONN SOCKET 100POS SMD GOLD |
| Category | Connectors, Interconnects |
| RoHS | Lead free / RoHS Compliant |
| Warranty | 365 days |
| Datasheet | - |
Product Attributes
| Type | Description |
|---|---|
| Product Status: | Active |
| Connector Type: | Socket, Center Strip Contacts |
| Number of Positions: | 100 |
| Pitch: | 0.020" (0.50mm) |
| Number of Rows: | 2 |
| Mounting Type: | Surface Mount |
| Features: | Board Guide |
| Contact Finish: | Gold |
| Contact Finish Thickness: | - |
| Mated Stacking Heights: | 7mm, 8mm, 9mm |
| Height Above Board: | 0.238" (6.05mm) |
